Hegel H20 Power Amplifier
Hegel H20 Power Amplifier

Hegel H20 Power Amplifier


Hegel H20 Power Amplifier

The Hegel H20 incorporates the latest version of the Hegel FET-technology. A practical benefit of the H20 FET-technology is a more rhythmic sound. It is simply better at re-creating a bass line. Another vital element is the removal of harmonic echoes in the higher frequencies, which result in a lot more detail and still a smoother and more natural sound.

Technical Details

Output power: More than 200 W + 200 W in 8 ohms, Dual mono
Inputs: RCA unbalanced and XLR balanced
Speaker outputs: Two pairs of heavy-duty gold plated terminals
Input Impedance: Balanced 10 kohm, unbalanced 50 kohm
Frequency response: Less than +/- 0.2 dB deviation 20 Hz - 20 kHz
Phase response: Less than 2 degrees deviation 20 Hz - 20 kHz
Signal to noise ratio: More than 100 dB
Crosstalk: Less than -100 dB
Distortion: Less than 0.006% at 100 W8 ohm
Intermodulation: Less than 0.01% (19 kHz + 20 kHz)
Damping factor: More than 1000
Power supply: 1000 VA dual mono, 90,000 μF capacitors
Output stage: 20 pcs 15 A 200 W high speed, ultra-low distortion bipolar transistors
Power consumption: 60 W in standby switched on
Finish: Black
Dimensions/weight: 12 cm x 43 cm x 37 cm (HxWxD), weight 25 kg
Dimensions/weight US: 4.7" x 17" x 15" (HxBxD), weight 55 lbs
