dCS Vivaldi Apex DAC
The digital core of the Vivaldi system, our renowned DAC decodes audio with remarkable precision. Equipped with the latest generation dCS Ring DAC™ APEX, it offers unparalleled performance characterized by exceptional realism, depth, and emotional engagement.
KEY FEATURES
- dCS Ring DAC APEX™ hardware further reduces distortion and improves linearity for enhanced musical performance
- Utilizes the latest generation dCS Digital Processing Platform for state-of-the-art measured performance and unrivaled fidelity
- Designed for maximum flexibility by accepting audio data from a variety of digital sources
- Flexible output configuration can be optimized in systems with or without preamplifiers
- Comprehensive clocking architecture plus an auto-clocking mode used in the Vivaldi range improves ease of use and minimizes jitter
- USB interface allows easy connection to a computer, accepting PCM data at up to 24/384 and DoP (DSD/64 or DSD/128 over PCM)
- The interface runs in asynchronous USB mode, making the DAC immune to jitter from noisy computer master clocks
- Improved power supplies give lower running temperature and superior tolerance to AC supply variations
- Multi-stage regulation ensures sensitive analogue circuitry is unaffected by digital interference
- Separate power circuits for the digital and analogue sections further enhance the purity of the power supply
- Aerospace-grade machined aluminium chassis fitted with tuned acoustic damping panels reduces magnetic effects and vibration
- Features a full MQA™ decoder. This MQA™ implementation is unique, as it is the first opportunity to enable a DAC which, by providing exact rendering to beyond 16x (768 kHz), matches the desired temporal response with very low modulation noise
SPECIFICATIONS
Digital-to-Analogue Converter
Finishes: Silver or Black
Dimensions: 444mm x 435mm x 151mm high; Allow extra depth for cable connectors; Allow space for airflow around the unit
Weight: 16.2kg
DAC Topology: dCS proprietary Ring DAC™ topology, with a choice of 3MHz or 6MHz operation
Outputs: 1 x pair balanced outputs on 2x XLR connectors; Output levels: 0.2V, 0.6V, 2V, 6V rms for a full-scale input, set in the menu; Output impedance: 3Ω; Maximum load: 600Ω (10k-100kΩ recommended); 1x pair unbalanced outputs on 2x RCA connectors; Output levels: 0.2V, 0.6V, 2V, 6V rms for a full-scale input, set in the menu; Output impedance: 52Ω; Maximum load: 600Ω (10k-100kΩ recommended)
USB Interface: USB 2.0 interface on B-type connector, accepts 24-bit 44.1 – 384kS/s PCM, DSD/64 & DSD128 in DoP format
Digital Inputs: 4x AES/EBU inputs on 3-pin female XLR connectors, accepts 24-bit 32 – 192kS/s PCM & DSD/64 in DoP format; 2 x Dual AES pairs, accepts 24-bit 88.2 – 384kS/s PCM, DSD/64 & DSD/128 in DoP format; 2 x SPDIF on RCA Phono connectors, accepts 24-bit 32-192kS/s PCM & DSD/64 in DoP format; 1 x SPDIF on BNC connector, accepts 24-bit 32-192kS/s PCM & DSD/64 in DoP format; 1 x SPDIF on TOSLINK connector, accepts 24-bit 32 – 96kS/s PCM; 1 x SDIF-2 interface on 2x BNC connectors, accepts 24-bit 32 – 96kS/s PCM or SDIF-2 DSD (auto selected); Requires compatible Word Clock input, locked to the correct data rate
Word Clock Inputs: 3 x Word Clock Inputs on BNC connectors, accept standard Word Clock at 32, 44.1, 48, 88.2, 96, 176.4 or 192kHz; Data rate can be the same as the clock rate or an exact multiple; Sensitive to TTL levels; 1 x Word Clock Output on 1x BNC connector; In Master Sync Mode, a TTL-compatible 44.1kHz Word Clock is output; In Universal Master Mode, a 38.4kHz Word Clock is output for use with the Vivaldi Upsampler
Dynamic Range: Better than -113dB @ 20Hz-20kHz unweighted (6V setting); Better than -115dB, 20-20kHz; Better than -105dB @ 20-20kHz
Filter Options: PCM mode: 4 filters provide different trade-offs between Nyquist image rejection and phase response; 2 extra filters available at 44.1, 176.4, 192, 352.8 and 384kS/s; DSD mode: 4 filters progressively reduce out-of-audio band noise level (inherent in the 1-bit nature of DSD), plus Filter 5 which has an improved transient response
Loading: Loaded from CD-R via PCM inputs or PC via USB interface
Control: dCS Universal Remote is supplied as standard; RS232 (controlled by the Vivaldi Upsampler/app or a third-party device)
Power: Factory set for 100, 115, 220 or 230V AC, 50-60Hz
Power Consumption: 23 Watts typical / 50 Watts maximum
