Handmade
The high-frequency reproduction benefits from the ring radiator developed exclusively for Burmester, which ensures optimum transparency and resolution. Low-mid and mid-woofer are an advanced development based on an already proven drive unit, which also aids the B18 to achieve an impressive sound performance.
The highly complex crossover is in its own enclosure chamber, as is the mid-bass driver, whose own closed enclosure results in particularly clean midrange performance.
The B18’s sandwich-constructed base is made of a high-molecular-weight thermoplastic polymer in combination with other materials of high internal damping and rigidity for optimum decoupling of the speaker from the floor. The solid MDF front, in conjunction with the enclosure optimized using FEM analysis, ensures accurate, precise bass response and significantly reduces cabinet reverberation. In addition to the mechanical damping by a foam cylinder, the B18 speaker has a bass switch to adjust the bass response according to room conditions and personal listening taste.
Features
- Exclusive Burmester ring radiator for optimal transparency and resolution
- Further developed low-mid and midrange woofer
- A rear switch for bass adjustment in combination with the included bass reflex the supplied bass reflex plugs for several possibilities of room adaptation
- The massive torsionally stiff 48mm MDF front in combination with the optimized by FEM analysis for accurate and precise bass response and Bass response and reduces the reverberation of the cabinet significantly
- 2 ½ way bass reflex principle with separate closed enclosure for the mid-bass and separate bass reflex enclosure for the bass-midrange driver
- Solid loudspeaker base made of matched, vibration damping and stiffening materials to minimize vibration transmission
- Highly complex crossover in its own enclosure chamber
Specifications
Principle 2½ way bass reflex
Weight 34,8 kg
Height 1056 mm
Width 204 mm
Depth 401 mm
Rated power DIN EN 60268-5 120 W
Sensitivity at 2.83V/1m 88 dB
Nominal impedance 4 Ω
Frequency response +/-3 dB 42 Hz to 30.000 Hz
Tweeter Ring radiator
Mid-woofer 17 cm with glass fiber diaphragm
Low-midrange 17 cm with glass fiber diaphragm
Crossover frequencies 400 Hz / 2300 Hz
