Arcam A5+ Integrated Amplifier
Arcam A5+ Integrated Amplifier
Pre-Order Now, Stock Expected October 2025
The A5+ features an enhanced power supply design and cutting edge wireless capabilities straight out of the box. Snapdragon Sound delivers uncompressed digital audio via Bluetooth, while Auracast enables multiple compatible headphones or speakers to share music wirelessly, with no pairing required.
With a wide array of digital and analogue inputs, including a meticulously tuned phono stage, the A5+ ensures impeccable sound quality for everything from vinyl to streaming.
- Wireless audio with Bluetooth 5.4
- Featuring Snapdragon Sound for wireless lossless audio
- Featuring Auracast for connecting wireless headphones or speakers to play music in multiple spaces.
- Hi-res audio digital inputs
- ESS ES9018 DAC
- Meticulously tuned phono stage
- Class AB amplification
- 2x 50 Watts (8Ω) Power Output
- Compact remote control
- Solid aluminium dials
- Aluminium front, top, sides and rear panels
Specification
Continuous power output (0.5% THD) 2 channels driven
8Ω, 20Hz ‑ 20kHz 50W
4Ω, 1kHz, 75W
Harmonic distortion, 80% power, 8Ω at 1kHz 0.003%
Analogue Inputs
Number of inputs 3 (RCA pairs)
Signal/noise ratio (A‑wtd, ref. 50W, 1V input) 106dB
Frequency response 20Hz—20kHz ± 0.2dB
Phono (MM) Input
Input impedance 47kΩ + 100pF
Frequency response (ref. RIAA curve) 20Hz—20kHz ± 1dB
Digital Inputs
Supported Sample Rates (kHz) 192, 176.4, 96, 88.2, 48, 44.1
Bit depths (bit) 24, 16
Frequency response (filter 1) 20Hz—20kHz ± 0.2dB
Signal/noise ratio (A‑wtd, ref. 50W, 0dBFS) 109dB
Headphone Output
Maximum output level (RMS) into 32Ω/300Ω 2.5V/5V
Load range 16Ω ‑ 2kΩ
Wireless Specifications
Bluetooth Version 5.4; A2DP Sink/Source, AVRCP, BLE, Snapdragon Sound,
AAC, LE Audio, Auracast
Bluetooth Transmitter Frequency and Power 2,400 MHz to 2,483.5 MHz: <20dBm
General
Mains voltage 100V or 110–120V or 220–240V, 50–60Hz
Power consumption (maximum) 350W
Power consumption (standby) <0.5W
Dimensions W x D (including speaker terminals) x H (including feet) 431 x 344 x 83mm
Weight (net) 8.14 kg
Weight (packed) 11.36kg
Supplied accessories Mains lead(s)
Remote control with 2 x AAA batteries
Quick Start Guide
Important Safety Instructions
