Pass Labs X260.8 Monoblock Amplifier

Sale price$29,995.00
Faceplate: Silver

Pickup available at Audio Connection

Usually ready in 5+ days

Pass Labs X260.8 Monoblock Amplifier

Pass Labs X260.8 Monoblock Amplifier

Silver

Audio Connection

Pickup available, usually ready in 5+ days

515 Parramatta Road
Leichhardt NSW 2040
Australia

+61295610788

Why Shop at Audio Connection

  • Live Online Chat Support (8am - 8pm)
  • Free Australia Wide Shipping
  • We speak English, Mandarin, Cantonese & Vietnamese
  • Payment Plans with 0% Interest
  • Earn 10 KrisFlyer miles (Offer ends 30/09/2025), per $1 spent with Kris+ by Singapore Airlines
  • Your satisfaction is our priority — from first inquiry to after-sale support.

BUY NOW PAY LATER | INTEREST-FREE REPAYMENTS

  • Split your payments over 2, 6, 12 or 18 months.
  • 0% on your purchase, zero fees.
  • No minimum spend.
  • All you need is a valid credit card (Visa, Mastercard, Amex).
  • Choose "More Payment Options" below and choose "Monthly credit card payments" on the checkout screen.

Attention Jetsetters: Been considering a new hi-fi purchase? You don't want miss this..

Right now, if you spent $6.1k on a new amplifier, pair of speakers, or other hi-fi item, you could get a round trip flight to a destination like Singapore, Vietnam or Thailand for free.

BONUS MILES PROMOTION | From now until 30th September 2025 you can get 10 KrisFlyer miles for every dollar spent with us at Audio Connection — that’s more thantriple the normal reward rate! Click here for more details.

Need Help?

If you have any questions or need advice - give us a call on 02 9561 0788 during business hours or use our live chat service AEST 8am - 8pm everyday (you'll chat with a real person, not a bot!).

Pass Labs X260.8 Monoblock Amplifier - Pair

The X260.8 is a refined musical instrument delivering 260 watts into 8 ohms, and combines power and finesse with all the benefits of mono-block performance. It's measured performance - distortion, bandwidth, noise, and resolution is beyond reproach. Like all of the class A/B .8's, this amplifier has some class A bias, rewarding its listeners with a whole new zenith of sound quality.

SPECIFICATIONS

Class  AB
Type  Mono
Gain (dB)  26
Full Power @ 26 dB gain (V)  2.2
Low Frequency Response  1.5 Hz
High Frequency Response  100 KHz
Power Output /ch (8 ohm)  260
Distortion (1 KHz, full power)  1%
Input Impedance (SE & BAL Kohms)  50/100
Damping Factor  150
Output Noise (uV)  200
Current Draw @ Idle (Amps)  3.1
Power Consumption (Watts)  375
Temperature (deg C.)  53
Number of Chassis  1
Unit Dimensions (W x D x H) (In.)  19 x 21.25 x 7.5
Unit Weight (LBS)  88
