Pass Labs XS300 Monoblock Amplifier

The XS series monoblock power amplifiers represent the reference-quality, state-of-art amplifiers from Pass Laboratories. Through years of "spare no effort" endeavour, they represent the true pinnacle of music reproduction. The XS 300 delivers 300 watts, employs separate power supply and amplifier chassis' for lower noise and utilizes higher-power constant-current source. Single-ended bias current not only lowers distortion, but facilitates better control of its harmonic structure, tweaked and optimized through endless listening tests for your musical pleasure.


Class  A
Type  Mono
Gain (dB)  26
Low Frequency Response  1.5 Hz
High Frequency Response  100 KHz
Power Output/ch (8 ohm)  300
Distortion, (1 KHz, full power)  1%
Input Impedance (SE & BAL Kohms)  50/100
Damping Factor   200
Output Noise (uV)  100
Power Consumption (Watts)  900
Temperature (deg C.)  53
Number of Chassis  2
Unit Dimension (W x D x H) (In.)  9 x 27.5 x 11 x 2
Unit Weight (LBS)  134 / 172
