Features, Stereo version:
• Exterior design by Flemming E. Rasmussen
• Electronics design by Tom Møller
• Pure Dual Mono configuration
• Zero global negative feedback
• 64 very high current bipolar output transistors
• 1.040.000 μF (>1 Farad) capacitor bank
• Extremely low capacitance Class A J-FET input buffer
• Balanced dual differential class A input circuitry followed by a very fast symmetrical voltage amplifying Class A stage
• Fully regulated low noise power supply for all voltage amplifying stages
• DC servo coupling
• Frequency-independent damping factor
• Gryphon silver internal signal and power wiring
• Premium, massive Zn foil capacitors used for local power supply decoupling, with a loss factor ten-times lower than of metallized Polypropylene-film capacitors.
• 4-layer up printed circuit boards with pure copper traces up to 105 um thick
• Two separate, custom made 2000VA toroidal transformers
• Individual, mechanically-decoupled left/right transformer castings
• Separate linear power supplies for both digital and analogue circuits
• “Soft Start” turn-on prevents triggering of fuses or circuit breakers in home electrical systems
• Gold-plated Neutrik XLR input sockets for one balanced source per channel
• NEW Gryphon Gold-plated, Custom-built binding posts
• AC polarity indicator
• 12VDC link for remote power on and off
• Automatic Green Bias setting via Green Bias link or manual Low/Mid/High bias switch
• Firmware upgradeable via USB stick
• Non-intrusive protection system
• Standby power consumption < 0.5W
• Designed and manufactured in Denmark
Specifications, Stereo version:
• 2 x 210W @ 8Ω, 2 x 420W @ 4Ω, 2 x 800W @ 2Ω and 2 x 1490W @ 1Ω with 115V/230V AC supply
• Output impedance: 0.015Ω
• Bandwidth (-3dB): 0.3Hz to 330KHz
• Power Supply Capacity: 1,040,000uF in total
• Gain: +31,0dB
• Input Impedance, balanced (20-20000Hz): 20KΩ
• Dimensions: 593mm X 371mm X 886mm (W x H x D), 202kg net., each Stereo or Mono cabinet.
