Optional internally retro-fittable phono stage for MM and MC:
- User-selectable Load and Gain settings
- Low-noise hybrid JFET design
- User selectable MC Step-up transformer option for lowest noise
- Improved filtering against RF interference
TECHNICAL SPECIFICATIONS
TL2.5i Line Stage
Vacuum Tube Complement: 2 x 12AU72, 2 x 12AT7
Total Harmonic Distortion: 20Hz – 20kHz, 0.02%
Signal to Noise Ratio: 90dB
Maximum Output Voltage: 30 V RMS
Gain: 8dB or 14dB (user selectable)
Input Impedance: 50kΩ
Input Impedance: 200kΩ
Channel Separation: 75dB @ 1kHz
Power Consumption: 100 Watts (line) 150 Watts (with phono)
Primary Mains Fuse Rating: 100/120V = 1A Ceramic Slo Blo, 220/240V = 0.5A Ceramic Slo Blo
Dimensions: (W x D x H) 19 x 15 x 4″ / 48.3 x 38.1 x 10.2 cm
Weight: 25 lbs (11.34 kg) packed
TL2.5i Phono Stage |
MM |
MC (active) |
MC Step Up Transformer |
Vacuum Tube Complement |
2 x 12AX7 |
1 x 12AU7 |
|
Gain |
37dB |
52dB or 58dB (user selectable) |
60dB |
Load |
47kΩ, 100kΩ |
100Ω, 470Ω, 1kΩ, 5kΩ, 47kΩ |
100Ω, 470Ω, 1kΩ |
Signal to Noise Ratio |
80dB |
70dB |
75dB |
